SOL-N30-P Al 250 mm

Code: 88000431

SOL-N30-P Al 250 mm

Code: 88000431

Fastener designed for the landscape installation of PV modules parallel to the roofing. The roofing wave must have a minimum width of 22 mm. The fastener ensures the required offset from the base surface of the roofing. For larger double optimizers, it is recommended to use the SOL-N30 OPT optimizer fastener.

TECHNICAL DATA AND STANDARDS

LEGEND

MATERIAL
LABEL
MATERIAL
Rf
stainless steel
Rf*H4
acid-resistant stainless steel
Cu
copper
Al
aluminium
Fe
steel
FeZn
galvanized steel
FeZn-H
hot-dip galvanized sheet metal
KFe
polypropylen
FeCu
copper coated steel
Me
brass
PE
polyetilen - UV resistant
N
nylon – UV resistant
P-SV
polyester with UV resistant glass fibres
pvc
electrostatic plastic-coated
PVC
resistant synthetic material
Wood
wood
Concrete
concrete
Ltž
cast iron
CuSn
tinned copper
PP
polypropylen

CONDUCTOR DIMENSIONS

(appropriateness of holders for a certain profile of conductors)

LABEL
DESCRIPTION
Φ

round cross-section conductor
P

rectangular cross-section conductor


CONDUCTOR ATTACHMENT ON FASTENER

LABEL

DESCRIPTION
N

attachment with nylon attachment elements
PE

attachment with polyetilen attachment elements
K
click attachment system
V
screw attachment
*
upon request
Labels legend
Contact us
Fastener designed for the landscape installation of PV modules parallel to the roofing. The roofing wave must have a minimum width of 22 mm. The fastener ensures the required offset from the base surface of the roofing. For larger double optimizers, it is recommended to use the SOL-N30 OPT optimizer fastener.
Material Aluminium
Length 250 mm
Surface protection Other
Integrated cable duct False
Cable duct optional False
