The PKL-KO 90° elbow is bolted on the KL cable ladder with the PKL-FS fixed connecting element, which is installed on the outer side with PP M6x12 (8x) connection bolts and PP M6 (8x) flange nuts.
| Material | Stainless steel |
| Model | Without connector |
| Surface protection | Other |
| Stainless steel, pickled | NO |
| Suitable for circuit integrity | No |
| Wide span model | NO |
| Deflection (angle) | 90° |
| Cable ladder width | 200 mm |
| Cable ladder height | 60 mm |
| Side wall perforation | YES, YES |
| Type of rung | Perforated profile |
| Material quality | Other |
| Change of direction | Horizontal |
| Type of side joist | Profile (open) |
| Bend model | Other |
